Product Overview
The ACEIRMC VL53L0X Time-of-Flight (ToF) Laser Ranging Sensor Breakout 940nm GY-VL53L0XV2 Laser Distance Module I2C IIC (5pcs Purple) is engineered for everyday needs, featuring compact build and thoughtful design. Constructed using Silicon, Metal, Glass, PCB Material, measuring 0.79 x 0.39 x 0.39 inches. Notable features include st microelectronics and time-of-flight ranging, contributing to its time-tested character.
Key Features
- 1.The VL53L0X from ST Microelectronics is a time-of-flight ranging system integrated into a compact module. This board is a carrier for the VL53L0X, so we recommend careful reading of the VL53L0X datasheet (1MB pdf) before using this product.
- 2.The VL53L0 uses ST's FlightSense technology to precisely measure how long it takes for emitted pulses of infrared laser light to reach the nearest object and be reflected back to a detector, so it can be considered a tiny, self-contained lidar system.
- 3.Ranging measurements are available through the sensor's I⊃2;C (TWI) interface, which is also used to configure sensor settings, and the sensor provides two additional pins: a shutdown input and an interrupt output.
- 4.The VL53L0X is a great IC, but its small, leadless, LGA package makes it difficult for the typical student or hobbyist to use. It also operates at a recommended voltage of 2.8 V, which can make interfacing difficult for microcontrollers operating at 3.3 V or 5 V. Our breakout board addresses these issues, making it easier to get started using the sensor, while keeping the overall size as small as possible.
- 5.A time-of-flight ranging system integrated into a compact module
Why Choose the ACEIRMC VL53L0X Time-of-Flight (ToF) Laser Ranging Sensor Breakout 940nm GY-VL53L0XV2 Laser Distance Module I2C IIC (5pcs Purple)
The ACEIRMC VL53L0X Time-of-Flight (ToF) Laser Ranging Sensor Breakout 940nm GY-VL53L0XV2 Laser Distance Module I2C IIC (5pcs Purple) reflects deliberate reliable choices, with st microelectronics that supports long-term value during regular motion detectors use.
Best For
Buyers shopping for everyday needs will find the ACEIRMC VL53L0X Time-of-Flight (ToF) Laser Ranging Sensor Breakout 940nm GY-VL53L0XV2 Laser Distance Module I2C IIC (5pcs Purple) a strong match thanks to thoughtful design.
Quick Summary
The ACEIRMC VL53L0X Time-of-Flight (ToF) Laser Ranging Sensor Breakout 940nm GY-VL53L0XV2 Laser Distance Module I2C IIC (5pcs Purple) is a Motion Detectors product by ACEIRMC. Brand: ACEIRMC. Item dimensions L x W x H: 0.79 x 0.39 x 0.39 inches. Material: Silicon, Metal, Glass, PCB Material. Style: Modern. Current Rating: 150 Milliamps. Price: $26.38.
Product Specifications
| Specification | Details |
|---|---|
| Brand | ACEIRMC |
| Item dimensions L x W x H | 0.79 x 0.39 x 0.39 inches |
| Material | Silicon, Metal, Glass, PCB Material |
| Style | Modern |
| Current Rating | 150 Milliamps |
